Particulate Meters, Monitors, Instruments

For IAQ, PM2.5, PM10 Measurement, Data-Logging (and more)

GrayWolf’s 6-channel handheld, desktop, and wall-mount air particulate meters, PM2.5 and PM10 monitors, and particle counters all include high accuracy sensors and precision pumps. They interface with GrayWolf DirectSense®, AdvancedSense® XM, and WolfSense® LAP enabled instrumentation. They also can connect via WolfSense Mobile apps on Android and iOS devices. Use these particle meters as stand-alone instruments, and/or interface them to display and log particulate concentrations directly on a GrayWolf instrument, Mobile PC, smartphone/iOS, Android device, and/or to the cloud, all simultaneously with one or more GrayWolf multi-sensor probes.

GrayWolf IAQ Particle Meter (PM2.5, PM10)

PC-3016 – 6 Channel Particle Meter

PC-3500 (left), PC-4005 (center), PC-5000 (right) 6-channel Particle Meters

PC-3500 (left), PC-4005 (center), PC-5000 (right) 6-channel Particle Meters





  • Measure Particle Concentration/Counts as stand-alone meters
  • Simultaneously measure, in combination with GrayWolf probe parameters
  • Works in conjunction with GrayWolf DirectSense II IAQ probesToxic Gas probesTVOC probesAS-201/202A Air Velocity probes and/or Zephyr-LDP or DP-702LH auto-zeroing Differential Pressure sensors
  • 0.3µm and larger particles with GrayWolf’s PC-3016, PC-3500, PC-4000 and PC-5000 six size range particle meters which can display/log calculated mass concentration (as PM0.5, PM1.0, PM2.5, PM5.0, PM10 & TPM in µg/m3) or as particle counts Note: Particle Counts not available on WolfSense Mobile enabled devices at this time.
  • Use the particulate meters as unconnected dataloggers, downloading logged data direct to GrayWolf’s advanced data management and reporting software; WolfSense PC
  • Or interface the particulate meters to a GrayWolf AdvancedSense XM, WolfSense LAP enabled Windows tablet or WolfSense Mobile enabled iOS or Android device (optional GrayWolf manufactured WolfRadio™ XM module required) to store ALL survey information; data AND audio/text/photo/video notes
  • When interfaced, includes easily accessible, on-board parameter tips, an IAQ particle sizing chart, government and industry guidelines, help videos, optional GrayWolfLive® Wi-Fi access and much more
  • Optional WolfSense ARG Advanced Reporting software for highly efficient, detailed, automated reports
  • %RH and Temperature optionally available on all models
  • CO2 and TVOC sensors optionally available, built right into the PC-4005 or PC-5005, or utilize a DirectSense II probe
  • Up to 25 additional parameters, accessible for all models, when simultaneously interfaced to DirectSense II probe(s) via AdvancedSenseXM/Android, iOS or Windows devices/Cloud
  • Added available sensors include CO, NO2, O3, HCHO, NH3, Cl2, H2S and many more
WolfRadioXM 3016

WolfRadio-XM-3016 module for PC-3016 particle meter enables wireless connectivity to AdvancedSense XM, Android, iOS devices, and via Wi-Fi to the cloud via GrayWolfLive.

WolfRadioXM 3500 - Connect Particle Counter to Wi-Fi and Bluetooth

WolfRadio-XM-3500 module for PC-3500/4000/4005/5000/5005 particle meters enables wireless connectivity to AdvancedSense XM, Android, iOS devices, and via Wi-Fi to the cloud via GrayWolfLive.

PC-3016 6-Channel Particle meter in use with Bluetooth connection to 2 x DirectSense II IAQ probes and to Android device.

PC-3016 6-Channel Particle meter in use with Bluetooth connection to 2 x DirectSense II IAQ probes and to Android device.

AdvancedSenseXM Particle Meter

When connecting to an AdvancedSense XM meter, smartphone, Windows/iOS/Android device, or to the Cloud, Particulate readings may be displayed and logged on their own or in combination with other GrayWolf sensors.

PC-3500 with AdvancedSense Pro and DSII-8 Indoor Air Quality Probe

PC-3500 6-Channel Particle meter in use with cable connection to DirectSense II IAQ probe and to AdvancedSense meter.

Check out this brief overview of GrayWolf’s advanced Air Quality meters/instruments & how to organize a demonstration specific to your Particulate measurement needs.

Brochures

Particle Meter
Particle Counter
PC4000 Brochure
PC5000 Brochure
GWLive Brochure NEW
WolfSense PC
WolfRadioXM

Application Notes

LEED v4 EQc4

Download “USGBC LEED®
v4 EQc4 – Air Quality Assessment”

Well Building

Download “The WELL Building Standard v1, for Air Quality Screening”

Asthma Triggers Application Note

Download “Asthma Trigger Application Note”

WELL Building for Air Quality Monitoring and Feedback

Download “The WELL Building Standard v1, Section 18, Continuous Air Quality Monitoring and Feedback”

Performance Verification

Download “Performance Verification of Indoor Air Purification/Filtration Products”
